Introduction

Github uses a nice feature called OpenID Connect (OIDC) for Federated Authentication.

OpenID Connect (OIDC) allows your GitHub Actions workflows to access resources in Azure, without needing to store the Azure credentials as long-lived GitHub secrets.

For more information on how to setup you can read the GitHub documentation: Configuring OpenID Connect in Azure

Authentication is then done with the azure/login@v1 action.

    - name: 'Az CLI login'
      uses: azure/login@v1
      with:
          client-id: ${{ secrets.AZURE_CLIENT_ID }}
          tenant-id: ${{ secrets.AZURE_TENANT_ID }}
          subscription-id: ${{ secrets.AZURE_SUBSCRIPTION_ID }}

Possible Terraform issue

This is working fine for direct deployments with ARM or Bicep templates, however, when using the When tying to use the authentication with Terraform whith a Terraform plan or a terraform apply, you might bump into the following error:

Error: Error building AzureRM Client: Authenticating using the Azure CLI is only supported as a User (not a Service Principal). To authenticate to Azure using a Service Principal, you can use the separate ‘Authenticate using a Service Principal’ auth method - instructions for which can be found here: https://www.terraform.io/docs/providers/azurerm/guides/service_principal_client_secret.html

To enable Terraform to use OpenID Connect (OIDC)

Add the use_oidc = true section to the backend settings as explained in the azurerm documentation

Example azure.tf:

terraform {
  required_providers {
    azurerm = {
      source = "hashicorp/azurerm"
      version = "3.30.0"
    }
  }
}

provider "azurerm" {
  use_oidc = true
  features {}
}

Declare the environment variables in the GitHub workflow:

env:
  ARM_SUBSCRIPTION_ID: ${{ secrets.AZURE_SUBSCRIPTION_ID }}
  ARM_CLIENT_ID: ${{ secrets.AZURE_CLIENT_ID }}
  ARM_TENANT_ID: ${{ secrets.AZURE_TENANT_ID }}

You can find a working example on my GitHub TFdeploy repo
